| Type | Cable Range (mm) |
Thread O. D. AG (mm) |
Thread Length GL (mm) |
Spanner Size (mm) |
|---|---|---|---|---|
| M12 x 1.5 | 3~6.5 | 12 | 8 | 16 |
| M16 x 1.5 | 4~8 | 16 | 8 | 19 |
| M18 x 1.5 | 5~10 | 18 | 8 | 22 |
| M20 x 1.5 | 6~12 | 20 | 10 | 24 |
| M22 x 1.5 | 10~14 | 22 | 10 | 27 |
| M24 x 1.5 | 12~16 | 24 | 10 | 27 |
| M25 x 1.5 | 13~18 | 25 | 10 | 33 |
| M27 x 1.5 | 13~18 | 27 | 10 | 33 |
| M30 x 1.5 | 16~21 | 30 | 11 | 35 |
| M32 x 1.5 | 16~21 | 32 | 11 | 35 |
| M36 x 1.5 | 18~25 | 36 | 12 | 42 |
| M40 x 1.5 | 22~32 | 40 | 14 | 52 |
| M50 x 1.5 | 32~38 | 50 | 14 | 60 |
| M63 x 1.5 | 37~44 | 63 | 15 | 64 |
| M71 x 1.5 | 42~50 | 71 | 28 | 77 |
